Charcoal 4000kg Rice Husk Paddy Hull Stove With Cyclone

Place of Origin CHINA
Brand Name PRESUN
Certification ISO
Model Number XSL-45
Minimum Order Quantity 1set
Price USD 8500-16500
Packaging Details Appreance protection
Delivery Time 5-8 WORKING DAYS
Payment Terms L/C, T/T
Supply Ability 100 SETS PER MONTH

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New Fuel Firewood
Feeding Mode Manual Heating Mode Indirect
Ignition Mode Manual Product Name Rice Husk Burner
Packing Nuke Packing Weight 4000kg
Guaranty 1 Year Main Material Brick&cement
Highlight

4000kg paddy hull stove with cyclone

,

Rice Husk paddy hull stove

,

Charcoal 4000kg rice husk stove

Leave a Message
Product Description

4000 kg paddy hull stove paddy hull furnace with cyclone and auto feeder

Advantages

The biomass furnace is a new type charcoal machine, it could deal with raw materials such as wood waste, wood branch, sawdust briquette, palm shell, coconut shell and etc. This biomass carbonization is our latest carbonization equipment,which is a single tank dry distillation hoist type carbonization furnace. It has big diameter, large capacity, simple operation and wide applications for charcoal raw materials. Before the carbonization, the raw material can be shaped briquettes or shapeless material such as wood logs, wood strips etc. biomass carbonization with single tank rotary is to carbonize the biomass briquette into wood charcoal.



Technical parameters

Model XSL-45 XSL-60 XSL-90
Heating Mode Indirect
Ignition Mode Manual
Feeding Mode Manual/Automatic
Heating Temperature ≤ 100℃
Heating Supply 450,000 Kcalorie 600,000 Kcalorie 900,000 Kcalorie
Biomass Fuel Husk/Coal/Wood & Other Biomass Material
Husk Consumption 60~180 kg/hr 80~240 kg/hr 120~360 kg/hr
Input Voltage 3 Phase 220V/380V,50Hz
Power (kw) 4.5 5.2 6.2
Control Method Automatic Control
Dimensions(mm) 3500*1500*2200 3800*1500*2520 5000*1800*2520
Safety Devices Low temperature automatic alarm, Temperature automatic control function, Feeding system, Ash exhaust system, Air Damper
Supply Dryer Quantities 5HPX-15 3 sets 5HPX-15 4sets 5HPX-15 6 sets
5HPX-20 2 sets 5HPX-20 3 sets 5HPX-20 4 sets
5HPX-30 1 set 5HPX-30 2 sets

5HPX-30 3 sets















The smallest furnace could supply 300,000 Kcal per hours,so it could drive at least one set 20 tons batch dryer

Charcoal 4000kg Rice Husk  Paddy Hull Stove With Cyclone 0



Equipment contained if choose husk as the fuel

Items Descriptions
Auto Feeder system One blower with one husk bin
Ash cleaner  One rotoary stick with one blower
cyclone 60mm diameters cyclone
Control system PLC type control panel





Applications:

Charcoal 4000kg Rice Husk  Paddy Hull Stove With Cyclone 1

Charcoal 4000kg Rice Husk  Paddy Hull Stove With Cyclone 2

Charcoal 4000kg Rice Husk  Paddy Hull Stove With Cyclone 3



What We Can Offer

1) Whole turnkey project solution
included pre-cleaning machine,elevator,conveyor these essential equipment could also given from ourside
2) Plant design service
supply you all the possibly area required,the instllation diagram and draws for consideration
3) Instllation and commisioning service
professional engineer woud guide you for the assembling and commisioning of the machine
4) Full time online service
24 hours online technique service,ensure to solve the problem immediately
5) Enormous spare parts to support
easy broken spares and wearing parts would be send timely,no worry for drying season



Who Are We

Charcoal 4000kg Rice Husk  Paddy Hull Stove With Cyclone 4

PRESUN is a factory dedicated to Grain Processing Machinery,about us,few items you might need to know:



1)We are located at Hefei City,Anhui Prov,China

2)Have more than 11 years experience at grain drying industry

3)10,000 square meters workshop

4)5,000 sets dryer already installed worldwide

5)600-1,000 sets dryer sold every year

6)ISO 9001 certificated company

7)Listed company since 2017
