30 Tons Rice Paddy Dryer Machine Batch Type Circulating Dryer Machine For Sell
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Batch Type | Usage | Grain Drying |
|---|---|---|---|
| Condition | New | Body Dimension | 3000*2260*10140mm |
| Overall Dimension | 3570*4374*10140mm | Power | 12.45kw |
| Warranty | 1 Year | Certification | ISO |
Product Description
Introduction
Circulating Agriculture Machine rice Corn Paddy Rice Grain Dryer Machine with high capacity increase the mesh, raise the utilization ratio of plate and increase hot air through the area and speed up the drying, improve drying uniformity; Remove the upper screw conveyor structure,reduce grain damage rate and emptying time, improve the rate of whole grain.This vertical dryer is suitable for drying rice, wheat, corn, soybean and other grains.
Operation steps
1. Grain Loading The grain is raised to the top of the main engine silo through the hoist, and the grain is put into the drying box through the agitating device until it is full.
2. Running The elevator is running all the time. When the grain reaches the bottom under the action of self-weight, the elevator raises the grain to the top and dries slowly from top to bottom 3. Drying The hot air passes through the drying layer horizontally. The grain is fully contacted with the drying layer after heating, and achieved drying effect.
Features
1. The use of a unique rotary heating device, simple structure, practical. 2. Dryer operating temperature ≤70℃.(drying temperature is different for different materials) 3. The control system adopts Siemens control system of American brand, which can set different temperature interval and drying time. 4. Automatic series is safe and reliable with high working intensity. 5. Automatic control of heating and drying process, small heating temperature fluctuation, accurate control. 6. The product moisture content can be as low as 1 ~ 3%, at the same time can maintain the original color, aroma, taste andnutrition ingredients, and long shelf life.
2. Specifications:
| Model | PGD-15 | PGD-20 | PGD-30 | |
| Dimension |
2538*4321*10000 |
2600*4402*11700 |
4812*5113*12700 |
|
| Capacity (kg) |
Paddy | 2500-15000 | 3000-20000 | 4000-30000 |
| Corn | 2880-18900 | 3680-25000 | 4880-36400 | |
| Wheat | 2450-16200 | 3235-22800 | 4260-33400 | |
| Net Weight(kg) | 3500 | 4200 | 6000 | |
| Burner | Model | PBF-30 type biomass stove | PBF-30 type biomass stove | PBF-45 type biomass stove |
| Fuel | Biomass pellet rice husk dual-purpose furnace(independent research and development)/natural gas/liquefied petroleum gas | |||
TO INSTALL PRESUN GRAIN DRYER MACHINE FOR YOUR MILL?
Definitely Yes,Cause...
1)Full time processing ability,get rid of bad weathers' interruption,like raining,storm,snowing and etc
2)Massive Drying Capacity,one batch could reach 20 tons capacity,if connected with 5 sets,100 tons per day is available
3)Low-cost running consumption,Biomass material/coal/gas/diesel are all available
4)Flexible installation method,one furnace could connect 3 to 4 dryers,to save the land space
5)High processing efficiency,mo blind drying section,all the material would keep to the same mositure rate,make them the same quality
6)Slow and careful auger,tiny broken and waste material during the circulation
7)Best return on Investment ratio,running one to two month,could get back the investment on the machine
What We Can Offer
1)Whole turnkey project solution
included Pre-cleaning machine,elevator,input&outlet pipe,furnace and dryer
2)Plant designition service
supply you all the possibly area required,the instllation diagram for consideration
3)Instllation and commisioning service
professional engineer woud guide you for the assembling and commisioning the machine
4)Full time online service
24 hours online technique service,ensure to tackle the problem immediately
5)Enormous spare parts to support
easy broken spares and wearing parts would be send timely,no worry for drying season
Drying Unit Diagram
Applicantion:
